Secure image pipelines: SSRF to image bombs

Treat every remote image as an untrusted network request followed by an untrusted decoder input. A safe pipeline validates the source host, resolves and rejects internal addresses, pins the checked address to the connection, disables automatic redirects, revalidates every redirect target, caps bytes while streaming, limits decoded pixels and frames, bounds output dimensions, and runs inside a resource-limited process.

No single check covers the chain. A hostname allowlist without IP validation can reach internal services through DNS. A Content-Length check without a streaming ceiling trusts a header the origin controls. A 5 MB compressed file can still expand into a huge bitmap. A pixel ceiling does not replace a request timeout or a memory limit.

The defense sequence

untrusted URL
    │
    ├─ parse with a URL library; allow only http/https
    ├─ require an exact host or deliberate subdomain allowlist match
    ├─ resolve DNS; reject private, loopback, link-local, multicast, metadata ranges
    ├─ connect to the address that was checked
    │
    ├─ receive redirect? ── yes ──> resolve relative Location and repeat every check
    │                              stop after a small fixed hop limit
    │
    ├─ enforce timeout and streamed byte ceiling
    ├─ decode with pixel/page/channel safety limits
    ├─ apply bounded dimensions and expensive-operation policy
    └─ encode, cache, observe, and release resources

Add network egress policy around the process. Application checks reduce risk, but a container or VM that cannot route to metadata and private control-plane ranges gives you another independent boundary.

Threats and the control that actually stops them

Observation: Keenpix's current request path

Verified against repository code and tests on August 23, 2026, Keenpix currently applies these controls before a cold transform:

1. It parses the source with the platform URL implementation and accepts only http: and https:.
2. It fails closed when a project has no allowed origins. A host must equal an allowed name or be its subdomain.
3. It resolves a preferred IPv4 address, falling back to the resolver result, and rejects the private/routed classes implemented in safe-origin.ts, including loopback, RFC 1918, link-local, CGNAT, multicast/reserved IPv4, IPv6 unique-local/link-local/multicast, and mapped IPv4 forms.
4. It pins that selected address into the HTTP or HTTPS agent lookup so the connect does not perform a second unconstrained DNS decision.
5. It disables automatic redirects. Every accepted redirect is resolved relative to the current URL and passed through the complete origin validation again.
6. It checks declared length when present and always counts streamed bytes, aborting after the configured ceiling.
7. It passes raster bytes to Sharp with limitInputPixels and failOn: 'truncated', then caps output dimensions inside the transform steps.

The allowlist is checked before the internal cache read. A previously cached object does not let a source hostname bypass a later allowlist decision. Optional signed URLs are also verified before the cache lookup.

These are code observations, not a claim that the system is immune to SSRF, denial of service, or decoder vulnerabilities. The selected-address lookup is not the same as enumerating every A and AAAA answer, and application checks are not a substitute for egress controls.

Current repository defaults and hard stops

Self-hosted operators can override environment defaults, so record the effective values for each deployment instead of assuming these are active everywhere.

The origin byte limit bounds the buffer Keenpix reads before decoding; it does not predict decoded memory. The pixel limit bounds declared width × height; it does not turn a 50-million-pixel image into a cheap transform. Animation, color profiles, codec behavior, intermediate operations, and output buffers still consume CPU and memory.

Safe fetch pseudocode

The important property is ordering. Do not resolve safely and then call a client that performs its own unrelated lookup or follows redirects automatically.

async function fetchUntrustedImage(rawUrl: string) {
  let current = await resolveAllowedPublicTarget(rawUrl)

  for (let attempt = 0; attempt < 4; attempt += 1) {
    const response = await requestPinnedAddress(current, {
      followRedirects: false,
      maxBodyBytes: 20 * 1024 * 1024,
      timeoutMs: 8_000,
    })

    if (response.isRedirect) {
      if (attempt === 3) throw new Error('redirect limit exceeded')
      current = await resolveAllowedPublicTarget(
        new URL(response.location, current.url).toString(),
      )
      continue
    }

    if (!response.ok) throw new Error(`origin returned ${response.status}`)
    return response.readWithHardByteCeiling()
  }

  throw new Error('unreachable')
}

resolveAllowedPublicTarget must use a URL parser, not a regular expression; compare normalized hostnames against an allowlist; reject credentials and unexpected ports if your product does not need them; inspect IPv4 and IPv6; and return the checked address for the connection. The pseudocode leaves library-specific TLS/SNI details to the implementation. Copying it without a pinned, certificate-valid HTTPS connection is not sufficient.

OWASP recommends disabling redirect following to prevent redirect-based validation bypasses. If product requirements need redirects, manual revalidation like the sequence above is the safer contract.

Byte limits and image bombs are different gates

A body ceiling answers “how much compressed data will I buffer?” A pixel ceiling answers “how large a raster will I permit the decoder to construct?” Enforce both:

import sharp from 'sharp'

const output = await sharp(untrustedBytes, {
  animated: false,
  failOn: 'warning',
  limitInputChannels: 4,
  limitInputPixels: 40_000_000,
  sequentialRead: true,
})
  .resize({ width: 2048, height: 2048, fit: 'inside', withoutEnlargement: true })
  .webp({ quality: 80 })
  .toBuffer()

Sharp's official constructor documentation recommends its default failOn: 'warning' level for untrusted input and documents pixel, channel, page, and “unlimited” safety options. Keenpix currently uses failOn: 'truncated'; that is a repository observation, not the stricter general recommendation shown above.

Leave animation off unless the product needs it. If animation is required, test inputs with many frames and enforce an explicit page/work budget around the decoder. A width × height check alone does not express total animated work.

Do not set Sharp's unlimited: true for an internet-facing transform service. Keep the decoder and its native dependencies patched, run as a non-root user, mount a read-only filesystem where possible, remove cloud credentials from the transform process, and place temporary storage on a bounded volume.

Redirect policy needs a business decision

Redirects are not automatically safe or unsafe. Decide what your pipeline needs:

Keenpix currently uses the third policy. A redirect to a different host succeeds only if that host is also allowed and resolves to an accepted public address. Keep redirect targets out of logs when URLs can contain tokens; log the normalized host, path class, hop count, and rejection reason instead.

Network controls behind the application

Recommended production boundaries:

• deny routes from the transform workload to cloud metadata, loopback, private subnets, cluster control planes, and database networks;
• allow DNS only through the resolver you monitor;
• route public origin traffic through an egress proxy when you need one enforcement and audit point;
• separate the image data plane from control-plane credentials;
• run decoder work in a container or sandbox with CPU, memory, process, file, and temporary-storage limits;
• keep the transform health endpoints private, as described in health and operations.

Network policy should fail independently from URL validation. Test both. A unit test that mocks DNS does not prove a production container cannot reach 169.254.169.254.

Production test cases

Use hosts and fixtures you control. Never probe third-party internal ranges.

Capture response status, normalized rejection category, total duration, bytes read, redirect hops, decoder failure class, process RSS, restart count, and whether the request reached the origin. Do not log source query secrets or signing keys.

Failure signals worth alerting on

• a rise in 403 private-address or disallowed-host failures;
• redirect-limit failures or a new redirect target host;
• 413 responses and origin bodies ending exactly at the configured ceiling;
• 504 responses, open-socket growth, or origins approaching the timeout;
• decoder failures clustered by source host or file format;
• process OOM kills, native crashes, restart loops, or sustained RSS growth after requests complete;
• high cache-miss cardinality with normal source traffic;
• egress-deny logs for metadata, database, or cluster ranges;
• a patch release from Sharp/libvips or an image codec that addresses a security issue.

An HTTP 502 for an invalid image is expected input rejection, not proof that the service crashed. A healthy liveness probe after every request is also insufficient: correlate rejection status with memory and restart telemetry.

Production checklist

• Allow only http and https; reject credentials and unused ports.
• Fail closed when no source hosts are configured.
• Normalize and allowlist hosts without substring matching mistakes.
• Validate public IPv4 and IPv6 results and connect to the checked address.
• Disable automatic redirects; revalidate each hop and cap the chain.
• Enforce both declared-length and streamed-byte ceilings.
• Set per-attempt and total-request deadlines.
• Limit decoded pixels, channels, pages/frames, output dimensions, and expensive operations.
• Keep animation disabled unless it has a measured product requirement.
• Run patched native decoders with least privilege and bounded resources.
• Add network egress denies for metadata and internal networks.
• Require signed image URLs when callers must not create arbitrary variants.
• Test the rejection paths in the deployed network, not only in unit tests.

Explicit limits and non-guarantees

An origin allowlist does not authenticate the bytes at that host. A signed transform URL prevents query tampering; it does not make an origin private, stop replay, or patch a decoder. DNS pinning closes one time-of-check/time-of-use window but does not replace inspection of all relevant addresses and egress policy.

The defaults listed here come from the current public Keenpix source. They may be overridden in a self-hosted deployment, and this article does not assert the effective managed-cloud values. Review Keenpix security and data handling, the security concept reference, parameters, and your own deployment configuration.

Continue the operations cluster

Pair these input controls with a bounded cache-key design and cache-stampede and transform-capacity planning. To run the stack yourself, use the self-hosting operations guide and Docker production checklist. To use the managed path, start with the cloud quickstart or create a trial.

Sources and verification

Verified August 23, 2026 against the official OWASP SSRF Prevention Cheat Sheet, Sharp constructor and safety options, and current Keenpix origin validation, pinned fetch and redirect handling, Sharp pipeline, runtime defaults, and transform tests. The defense-in-depth recommendations go beyond current application code and are labeled accordingly; no security guarantee is implied.
