Stop cache stampedes in image transformation

Prevent an image cache stampede at three boundaries: let the outer cache collapse a cold fill, coalesce identical work inside the transform service, and admit only as many distinct cold transforms as the CPU and memory budget can finish safely. Serve stale bytes during refresh when the image contract permits it. Reject excess cold work quickly instead of building an unbounded queue.

A single-flight map solves “100 requests for the same key.” It does not solve “100 requests for 100 different widths,” a multi-replica cold start, or a purge that invalidates a large catalog. Capacity planning starts where key-level coalescing ends.

The desired cold-request path

clients
   │
   ▼
edge cache ── warm/stale ───────────────────────────────> bytes
   │ cold key
   ▼
shared cache-fill lock ── followers wait with a deadline
   │ leader
   ▼
origin shield / Keenpix cache ── hit ───────────────────> bytes
   │ distinct cold transform
   ▼
bounded admission ── full ──> 503 + short Retry-After
   │ admitted
   ▼
fetch within byte/time limits → decode/transform → durable cache write → bytes

The lock is per effective representation, while admission is global or tenant-partitioned. Mixing them is a common mistake. A thousand unique cold keys pass through a thousand independent locks and can still overload the host.

Observation: what Keenpix does today

Verified from the public repository on August 23, 2026:

• Keenpix checks memory, then Dragonfly when configured, then S3-compatible object storage; local development can use disk instead. Lower-tier hits are promoted upward, and writes go to the durable tier before hot tiers.
• A stale internal entry is returned immediately. One background refresh starts when the current process has no refresh for that key.
• A missing key is stored in an in-process Map while fetch, transform, and cache write run. Other requests for the same hash await that promise instead of repeating the transform.
• The key contains project id, source URL, and full effective transform options. Different widths, formats, qualities, crops, or watermark configuration are deliberately different work.
• The Sharp wrapper sets sharp.concurrency(1), limiting libvips to one worker thread per image. Sharp documents that some codec libraries, including AVIF encoders, can create additional threads independently.
• KEENPIX_WORKER_CONCURRENCY controls durable prewarm jobs. It does not bound normal synchronous HTTP image transforms.

The current single-flight map is process-local. Two transform replicas can both miss shared storage and perform the same transform. The current public HTTP transform path also has no application-level global semaphore or bounded wait queue. Health readiness can return 503 for failed dependencies, but that is not general overload shedding.

Those are explicit product limits, not measured incidents. The recommendations below describe how an operator can add the missing outer/shared and admission boundaries without claiming that Keenpix already supplies them.

Four different stampedes

The first response is not “add more retries.” Retries multiply load unless they are limited, delayed, and jittered. If a transform returns 503, the caller should retry only when the request still matters, honor Retry-After, use exponential backoff with jitter, and cap attempts.

Add a cache-fill lock at the proxy

Nginx documents proxy_cache_lock specifically to allow one request at a time to populate a new cache element while followers wait for the cached response or a lock timeout.

proxy_cache_path /var/cache/nginx/keenpix levels=1:2 keys_zone=keenpix:20m
                 max_size=20g inactive=30d use_temp_path=off;

location /img/ {
    proxy_pass http://keenpix_transform;

    proxy_cache keenpix;
    proxy_cache_key "$scheme$host$request_uri";
    proxy_cache_lock on;
    # Illustrative only: replace these from measured cold-fill latency and the
    # end-to-end client deadline. Do not copy them as universal safe values.
    proxy_cache_lock_timeout 20s;
    proxy_cache_lock_age 30s;

    proxy_cache_background_update on;
    proxy_cache_use_stale error timeout updating http_500 http_502 http_503 http_504;

    add_header X-Cache-Status $upstream_cache_status always;
}

This example assumes explicit output formats or separately proven Vary: Accept behavior. Read the cache-key and Vary guide before copying it.

The 20s/30s values are placeholders, not Keenpix defaults. Set proxy_cache_lock_timeout above the measured high-percentile cold-fill duration plus margin and below the end-to-end client deadline. Nginx documents that a waiter whose lock timeout expires is passed to the upstream and its response is not cached. If many waiters expire together, they can fan out into duplicate transforms. proxy_cache_lock_age is a separate escape hatch: when the active fill exceeds that age, Nginx may pass one more request upstream.

Therefore, a cache lock is not an admission controller. Pair it with the bounded cold-work gate in the next section before production, and alert on lock timeouts and age releases. If no timeout fits between measured cold latency and the client deadline, fail or serve stale at a real admission boundary instead of relying on the lock to protect capacity. An unlimited wait merely moves an unbounded queue into the proxy.

proxy_cache_use_stale updating and background update can keep serving a previous image while one refresh runs. RFC 5861 defines the same availability pattern through stale-while-revalidate and stale-if-error. Use stale delivery only when the URL is versioned or the business accepts temporary old bytes. Do not serve a stale private or revoked image merely to improve availability.

Bound distinct cold work

Use a semaphore or proxy/orchestrator admission limit around cold transforms, not around cache hits. A practical policy has three outcomes:

warm hit       -> serve immediately
cold + slot    -> transform
cold + no slot -> wait for a very short bounded interval, then 503

At Nginx, a simple connection boundary can shed excess requests while you implement a cold-aware application gate:

limit_conn_zone $server_name zone=keenpix_transform_conn:10m;

location /img/ {
    limit_conn keenpix_transform_conn 16;
    limit_conn_status 503;

    proxy_connect_timeout 2s;
    proxy_read_timeout 20s;
    proxy_send_timeout 20s;
    proxy_pass http://keenpix_transform;
}

This counts proxied connections, so it is less efficient than a gate that distinguishes an internal cache hit from a cold transform. It is still a safer emergency ceiling than allowing memory to determine the limit through an OOM kill. Preserve a separate lightweight health route outside the limit.

Do not reuse KEENPIX_WORKER_CONCURRENCY as if it controlled HTTP traffic. Reduce or pause prewarm concurrency during a live cold-miss surge; background warming should yield to user requests.

Capacity is constrained by CPU, memory, and origins

Benchmark on the same CPU architecture, container limits, Sharp/libvips build, and formats used in production. Build a representative fixture set:

• small JPEG thumbnails;
• large camera JPEGs near the pixel ceiling;
• transparent PNG product images;
• WebP and AVIF inputs;
• animated inputs only if enabled;
• watermark and expensive crop/effect combinations;
• slow and fast origin responses.

For every fixture, record cold service time, CPU time, peak RSS delta, origin bytes, output bytes, format, dimensions, and whether the durable cache write completed. Do not publish a universal “transforms per second” number from one synthetic image.

Use two starting calculations:

memory-bound slots = floor((container memory limit - baseline RSS - safety headroom)
                           / measured p95 peak RSS delta per transform)

CPU-bound slots ≈ floor(usable CPU cores / measured p95 core demand per transform)

Choose the lower result, then lower it again if origin sockets, object-storage writes, or tail latency fail first. These are planning formulas, not queueing guarantees. Workloads overlap imperfectly, native memory is not always returned immediately, and format libraries can use threads outside Sharp's configured libvips concurrency.

Keep explicit headroom for the runtime, memory cache, network buffers, native allocator fragmentation, logging, and health checks. Kubernetes documents that CPU limits throttle CPU time while exceeding a memory limit can invoke the OOM subsystem and terminate the process. A memory limit is a final containment boundary, not an admission algorithm.

Run a stepped load test, not one maximum blast

1. Warm the durable cache and measure the hit path separately.
2. Purge only the controlled fixture keys.
3. Send one cold request at a time to establish service-time and memory baselines.
4. Increase distinct-key concurrency in small steps: 1, 2, 4, 6, 8....
5. Hold each step long enough to observe steady CPU, RSS, queue depth, and p95/p99 latency.
6. Stop before OOM, sustained CPU throttling, growing queues, origin saturation, or readiness failure.
7. Repeat with identical-key bursts to verify coalescing independently.
8. Repeat across two replicas to expose duplicate work that a process-local map cannot prevent.

Capacity is the highest step that meets the error and latency objective with headroom, not the last step before the container dies. Document the fixture mix and build identifiers alongside the result.

Metrics that reveal overload early

Keenpix exposes transform liveness/readiness and a separate worker Workbench for prewarm jobs. Keep those service-local operator surfaces private. See health and operations for the probe boundary.

Failure patterns and first actions

One hot key, many origin fetches

Confirm that the public cache key is identical, query order is canonical, and format variation is bounded. Then test the same burst against one process and multiple replicas. If one process coalesces but two do not, add an outer cache-fill lock or a distributed lease with a short expiry and owner token.

Many unique misses after a frontend release

Inspect emitted widths, DPRs, qualities, and query parameters. Roll back an unbounded responsive ladder, not the cache. Enable signed URLs if untrusted callers can manufacture variants.

RSS climbs while CPU is not saturated

Reduce admission concurrency, inspect input pixels/animation and Sharp cache statistics, and verify container memory limits. Do not raise the memory limit until the fixture identifies whether the increase is expected working set, native fragmentation, or retained data.

CPU is saturated and latency grows

Reduce cold slots or scale replicas only if the shared cache and origin can support them. More replicas without an outer fill lock may multiply identical cold work. Prefer explicit WebP/JPEG during an incident if AVIF encoding is the dominant cost and that format change is compatible with the URL contract.

Cache writes fail

Serve the completed response if policy allows, but alert immediately: every subsequent request may recompute the same key. Check Dragonfly/object-storage readiness, credentials, capacity, latency, and whether the durable tier is written before hot-tier promotion.

Safe retry contract

When admission is full, return a short response:

HTTP/1.1 503 Service Unavailable
Cache-Control: no-store
Retry-After: 2
Content-Type: text/plain; charset=utf-8

Image transform capacity is temporarily full.

Do not cache the overload response under the image's long immutable policy. At clients or prewarm workers, cap retries and add jitter:

const delayMs = Math.min(8_000, 250 * 2 ** attempt)
const jitteredMs = Math.round(delayMs * (0.5 + Math.random()))

Interactive browser image loads may not implement application retries at all; the CDN's stale/error policy is usually the better availability mechanism. Durable prewarm work can retry later because it is not on the user path.

Production checklist

• Use a correct, bounded cache key before optimizing hit rate.
• Enable one cache-fill leader per outer-cache key with a finite wait and lock age.
• Serve stale during refresh only for content whose freshness policy allows it.
• Coalesce identical work inside each process and test cleanup after success and failure.
• Add a global or tenant-aware limit for distinct cold transforms.
• Keep the waiting queue short and return 503/Retry-After before memory exhaustion.
• Measure representative cold transforms on the production CPU and memory boundary.
• Set concurrency from the lower CPU/memory/origin constraint with explicit headroom.
• Reserve live capacity; pause or reduce prewarm work during demand spikes.
• Version URLs and stage purges instead of invalidating an entire hot catalog at once.
• Monitor edge and internal cache status, unique in-flight keys, Sharp counters, CPU throttling, RSS, OOMs, origin failures, and cache-write failures.
• Test one process and multiple replicas; document where duplicate work can occur.

Explicit limits and non-guarantees

Keenpix currently coalesces identical requests and refreshes stale internal entries within a process. It does not currently promise a distributed single-flight lock, a configurable HTTP transform semaphore, or a universal 503 overload response. KEENPIX_WORKER_CONCURRENCY is limited to prewarm workers.

This guide provides no Keenpix throughput, latency, cache-hit, or memory guarantee. The safe slot count depends on sources, pixels, formats, effects, native libraries, hardware, container limits, and traffic mix. Use the parameter reference and input-security guide to bound the worst cases before load testing.

Continue the operations cluster

Start with image CDN cache keys and Vary: Accept, then apply SSRF, redirect, byte, and image-bomb defenses. The AVIF vs WebP production guide covers format-specific cache testing. For activation, follow the managed cloud quickstart, start a trial, or use the self-host deployment path.

Sources and verification

Verified August 23, 2026 against the official Nginx proxy cache lock and stale directives, RFC 5861 stale-while-revalidate and stale-if-error, Sharp queue, cache, counters, and concurrency documentation, AWS overload mitigation guidance, and Kubernetes container resource behavior. Keenpix observations were checked against the current public transform runtime, cache coordinator, Sharp wrapper, prewarm worker, and tests. Capacity formulas and limits are recommendations to validate, not product benchmarks.
