Self-host an image CDN with Docker: production checklist

docker compose up -d can leave you with seven healthy containers and an unsafe deployment. The database may have no backup, image tags may drift across services during the next pull, or a proxy may cache the sign-in page along with transformed images.

This setup treats the first successful container start as the beginning of the job. It uses the Compose file in the Keenpix repository, pins a release, and checks the pieces that carry state.

What the Compose stack runs

The repository's docker-compose.yml starts seven services:

• PostgreSQL 18 on the private Compose network, with a named database volume;
• Dragonfly for queues and shared hot-cache metadata;
• MaxIO for the shared S3-compatible image cache;
• the app control plane, transform data plane, BullMQ worker, and standalone docs service.

The stateful and Keenpix services have readiness checks. The app waits for its dependencies, runs Prisma migrations and the initial seed through its entrypoint, then serves /api/health on port 3000. The Keenpix containers run as the unprivileged node user.

The database volume is durable state. Back it up. The image cache can be rebuilt from the origin and should not be treated as a backup of your source images.

Pin the release before starting

The Compose file defaults to the moving latest image. For a controlled installation, check out a release and pin the matching container tag:

git clone --branch v0.3.0 --depth 1 https://github.com/lord007tn/keenpix.git
cd keenpix
cp .env.example .env

Set at least these values in .env:

KEENPIX_APP_IMAGE=ghcr.io/lord007tn/keenpix-app:v0.3.0
KEENPIX_TRANSFORM_IMAGE=ghcr.io/lord007tn/keenpix-transform:v0.3.0
KEENPIX_WORKER_IMAGE=ghcr.io/lord007tn/keenpix-worker:v0.3.0
KEENPIX_DOCS_IMAGE=ghcr.io/lord007tn/keenpix-docs:v0.3.0
POSTGRES_PASSWORD=<a-long-random-password>
BETTER_AUTH_SECRET=<output-of-openssl-rand-hex-32>
BETTER_AUTH_URL=https://admin.images.example.com
KEENPIX_APP_URL=https://admin.images.example.com
KEENPIX_SUPER_ADMIN_EMAIL=admin@example.com
KEENPIX_SUPER_ADMIN_PASSWORD=<a-different-long-password>

Generate the auth secret instead of typing the placeholder:

openssl rand -hex 32

Then pull and start the exact image:

docker compose pull
docker compose up -d
docker compose ps

Do not publish PostgreSQL's port to the internet. The supplied Compose file keeps it private and only publishes the Keenpix application port.

Put TLS and caching in the right places

Terminate HTTPS at Caddy, Nginx, Coolify's proxy, or a CDN. Set BETTER_AUTH_URL and KEENPIX_APP_URL to the public dashboard URL so cookies and generated links use the same origin.

Cache only /img/*. Keep /app, /api/auth, /api/health, and the rest of the dashboard outside the cache rule. A broad "cache everything" rule can store authenticated or session-dependent responses.

The cache key must include the complete path and query string. These requests are different image variants:

/img/https://assets.example.com/hero.jpg?project=store&w=640&fmt=webp
/img/https://assets.example.com/hero.jpg?project=store&w=1200&fmt=webp

If you use fmt=auto, the outer cache must also separate variants by Accept. Use explicit fmt=avif, fmt=webp, or fmt=jpeg when the CDN cannot prove that behavior.

Create a project and run a smoke test

Sign in with the bootstrap admin account, create a project, and add the source hostname to its allowed-host list. Then request one known image:

curl -sS -D transform.headers -o transformed.webp \
  'https://images.example.com/img/https://assets.example.com/catalog/chair.jpg?project=PROJECT_ID&w=1200&fmt=webp&q=80'

Check these facts instead of stopping at HTTP 200:

• Content-Type is image/webp;
• Cache-Control keeps the transform cacheable;
• the returned dimensions match the request and source limits;
• a source hostname outside the allowlist is rejected;
• a repeated request becomes a hit at the cache layer you intended to test.

Also check the service health and recent logs:

curl -fsS https://admin.images.example.com/api/health
docker compose logs --since=10m app

The health response proves that this instance can answer its configured checks. It does not test every source, transformation, or CDN region.

Back up Postgres before the first upgrade

Create and test a database-backup routine before users add projects or invitations. A simple manual dump from the bundled service is a useful first check:

docker compose exec -T postgres sh -lc \
  'pg_dump -U "$POSTGRES_USER" -d "$POSTGRES_DB" -Fc' \
  > keenpix-$(date +%F).dump

Store backups away from the Docker host. A named volume protects data from routine container replacement, but it does not protect against disk loss, operator mistakes, or a damaged database.

Before an upgrade, read the release notes, take a fresh dump, change all four KEENPIX_*_IMAGE variables to the selected version, then run:

docker compose pull app transform worker docs
docker compose up -d app transform worker docs
docker compose ps

The entrypoint applies database migrations. Keep the previous image reference and a verified restore procedure available until the smoke tests pass.

Capacity choices you still own

The default Compose cache cap is 8 GB. Set KEENPIX_CACHE_MAX_BYTES from the actual disk budget, then watch eviction behavior. The HTTP transform runtime does not currently expose a global concurrency setting; add bounded admission control at the proxy or orchestrator so cold traffic sheds before the host runs out of memory. Use the cache stampede and transform capacity guide to measure a safe limit.

Horizontal self-hosted replicas do not share Keenpix's local disk cache. The bundled stack uses MaxIO for its shared object-storage tier; production operators can replace it with R2 or another S3-compatible service. Put a CDN in front of the transform service. PostgreSQL also needs a deliberate high-availability and backup plan if the service matters to production traffic.

When managed Keenpix is the better choice

Self-hosting removes the managed-service bill, not the operations work. Choose it when infrastructure control, data placement, or the ability to modify the AGPL-3.0 code matters enough to own upgrades, monitoring, backups, abuse controls, and incident response.

Use the managed service when the team wants image delivery without maintaining that stack. The transform URL concepts are similar, but the operational responsibility is not.

Sources and verification

This guide was updated on August 18, 2026 for Keenpix v0.3.0, the repository's four Dockerfiles and docker-compose.yml, the deployment presets, configuration reference, and CDN setup. The commands are an installation checklist, not a claim that every production deployment takes the same amount of time.
