Image delivery troubleshooting: diagnose by symptom

Troubleshoot image delivery from the visible symptom backward: browser selection, response headers, delivery cache, transform service, then origin. Preserve one failing URL and one known-good URL before changing anything. Random purges and quality changes often erase the evidence without fixing the cause.

Capture a minimal evidence bundle

For one failing request, record:

Page URL:
Image request URL with secrets removed:
UTC timestamp:
Browser and viewport:
currentSrc:
HTTP status:
Content-Type:
Cache-Control / Age / ETag / Vary:
Decoded and natural dimensions:
Cold and immediate-repeat timings:
Origin object status and MIME type:
Recent configuration or release change:

Do not paste API keys, signing secrets, cookies, private origin URLs, or customer data into tickets. A redacted URL must retain the hostname, path shape, parameter names, and status needed to reproduce the class of failure.

Symptom: the image is broken or returns 4xx

400 or 422

Suspect an invalid parameter, unsupported format, dimension limit, malformed source encoding, or signature input mismatch. Compare the URL against the documented parameter names and canonical order. If a signature covers the path or query, changing even an encoded slash can invalidate it.

401 or 403

Identify which layer rejected the request. A delivery signature failure, CDN firewall rule, transformer allowlist, origin authorization policy, and expired presigned URL can all return 403. Response headers and logs should name the layer without exposing credentials.

404

Check whether the delivery route exists before assuming the source is absent. Then decode the embedded source URL and request it from the transformer's network context. Object-store keys are often case-sensitive. Redirecting a missing path to an HTML error page can turn a clear 404 into a later decoder failure.

429

Determine whether the limit belongs to the edge, transform service, origin, or account. Preserve Retry-After if provided. Retrying every image immediately can amplify a small capacity problem into a stampede.

Symptom: 5xx, timeouts, or intermittent failures

Use bounded retries only for idempotent reads and add jitter. A transform request may be safe to retry, but a purge, key rotation, or project mutation needs its own idempotency design.

Symptom: the image is slow

Split the timing into DNS, connection, TLS, time to first byte, transfer, decode, and render. A large duration alone does not tell you whether the source, transform, cache, network, or browser is responsible.

1. Repeat the exact URL. If the second response is much faster, investigate cold transform and cache-fill behavior.
2. Inspect Age, provider cache headers, and Server-Timing if present. A faster repeat without a cache signal is not proof of a hit.
3. Request the source from the transformer's region. A fast origin from your laptop can still be slow from the service.
4. Compare transferred bytes and decoded dimensions with the rendered slot.
5. Check whether the image was discovered late because of CSS, client rendering, lazy loading, or an incorrect priority hint.
6. Use the reproducible measurement protocol before comparing providers.

Symptom: the image is too large

Inspect Content-Type, Content-Length, dimensions, quality, metadata, and animation. Common causes include an explicit PNG output for a photograph, a browser selecting the largest srcset candidate because sizes is wrong, format negotiation cached without Vary, an animated source that bypasses the intended path, or a transformer preserving dimensions the layout never uses.

Do not reduce quality globally as the first fix. That can damage text and product-detail images while leaving the selection error intact.

Symptom: the crop is wrong or blurry

Compare four sizes: source pixels, requested output, decoded output, and CSS-rendered box. Then check object-fit, aspect ratio, crop mode, focal position, device pixel ratio, and upscaling policy.

• Blurry only on dense screens usually means the candidate ladder stops too early.
• A correct desktop crop and wrong mobile crop usually means one focal rule is being reused across different aspect ratios.
• A sharp image that shifts the layout needs explicit intrinsic dimensions or aspect-ratio; more pixels will not fix the shift.
• Text or line art can look worse at a lower lossy quality even when photographs look acceptable.

Symptom: stale or inconsistent images

First ask whether the URL is immutable. If the source bytes can change at the same URL, every cache between the origin and browser needs a refresh policy. Compare ETag, Last-Modified, Age, cache key, purge scope, and any stale-serving directive.

Versioned asset URLs are usually safer than global purges:

/product/hero.jpg?v=2026-09-02

If format negotiation is automatic, request the same URL with explicit Accept: image/avif, Accept: image/webp, and a legacy value. An AVIF response reused for a client that did not request it points to incomplete cache variation. See cache keys and Vary.

Verify the fix

• Reproduce the original failure before applying the change.
• Change one boundary at a time.
• Repeat the original URL and a new uncached variant.
• Test a supported client, an unsupported format, an allowed source, a blocked source, a large safe fixture, and a normal fixture.
• Check desktop and mobile currentSrc, output dimensions, visual crop, and layout shift.
• Confirm logs identify the rejection layer without recording secrets.
• Leave a rollback trigger and observation window proportional to cache lifetime.

Using Keenpix during diagnosis

For Keenpix, start with the response status and documented transform endpoint, then check project origin allowlists, signed URL configuration, and delivery analytics. Self-hosted operators should also check the health and operations guide. Managed users can provide a redacted failing URL and timestamp through support.

Keenpix is not the right diagnostic target when the browser never requests the Keenpix URL, the origin object itself is broken, or another CDN rewrites or blocks the response first. Fix the owning layer or remove the intermediary before attributing the symptom.

Sources and limitations

• Chrome DevTools Network reference, reviewed September 2, 2026.
• HTTP response status codes, MDN, reviewed September 2, 2026.
• HTTP caching, MDN, reviewed September 2, 2026.
• Resource Timing Level 2, W3C, reviewed September 2, 2026.

Header names differ by CDN, and a cache hit does not prove a globally healthy service. This procedure produces a reproducible boundary diagnosis, not an uptime or performance guarantee.
